AUTOMATIC GLASS SLIDING DOOR

Cronax’s Glass sliding doors offer both functional benefits and aesthetic appeal, especially when they are customized to meet specific needs. These doors are particularly popular for small openings in corporate and administrative settings, serving as entrance doors that provide a transparent view of the interior spaces. This transparency not only enhances the visual appeal but also reflects a sense of sophistication, making them a symbol of status for many businesses.

Beyond their visual charm, glass sliding doors are highly efficient in functionality. Automatic sensor doors, for instance, offer seamless operation, ideal for frequent use. These doors can be easily programmed for optimal opening and closing timings, while maintenance requirements are minimal. Thus, they offer a convenient and customized solution for automated entrance systems.

Glass sliding doors find widespread usage in commercial buildings, shopping complexes, offices, and corporate environments. They are also commonly used as internal doors within industries. Manufactured in advanced facilities, these doors can be tailored to specific design preferences and operational needs. Whether manually operated or equipped with smart drives and controls, glass sliding doors promise easy assembly and programming, ensuring a seamless experience for users.

Cronax deals in all kind of sliding doors for industrial and commercial use. “glass sliding doors,” “automatic sensor doors,” “entrance door automation,” “commercial doors,” and “customized door solutions.”

AUTOMATIC GLASS SLIDING DOOR

1.Experience High Frequency Usage:

2.Swift Operation: Our doors smoothly open and close at adjustable speeds ranging from 100 to 450mm/sec.

3.Robust Top Mounted Track: Equipped with a heavy-duty top-mounted track featuring a reliable timing belt.

4.Unobstructed Passage: No hindrance at the bottom ensures seamless passage.

5.Diverse Panel Options: Choose from a wide range of standard and economical panel types to suit your building’s structural requirements.

6.Versatile Construction: Customize your doors with a combination of pre-coated panels or aluminum sheets alongside glazing sheets.

7.Enhanced Sealing: Automatic Glass Sliding Doors can incorporate vertical EPDM rubber seals for improved insulation and weatherproofing.

8.Secure Interlocking: Offering an interlocking feature between two doors for added security.

9.Additional Safety Features: Ensure safety with optional actuators such as radar detectors, push buttons, loop detectors, or remote controls integrated into the control system.

*Click to view in full size

TECHNICAL SPECIFICATION DESCRIPTION
PRODUCT

DOOR TYPE
AUTOMATIC SLIDING GLASS DOOR

SINGLE SIDE / BI PARTING TYPE
WIDTH MIN/MAX

HEIGHT MIN/MAX

Single Leaf : 2 Panels : 900mm to 2500mm
Double Leaf : 1500mm to 3000mm

1800mm – 2500mm (Larger Dimension on Request)
DOOR MOUNTING

OPENING DIRECTION

MOUNTING LOCATION

MOUNTING SURFACE

WIND RESISTANCE

ON TOP TRACK MECHANISM

HORIZONTAL

INSIDE/OUTSIDE

ON RCC/STEEL

UPTO 90 KM/HR.
(higher wind pressure on request)
DOOR PANEL

CONTOL UNIT

ROLLERS
Options Galore: Fully Glazed | Fully Paneled/Sheeted | Partially Glazed/Partially | Paneled/Sheeted | Explore a Range of Options for Glass, Panels, and Sheets sides.

Our advanced control system seamlessly integrates with all accessories. It automatically synchronizes master/slave selection for two motors, offers preset options for auto/partial opening/closing, and allows customization of operation sequences.

Top rollers feature a dual-type assembly with bearings, ensuring smooth operation. Bottom rollers are equipped with bearing assemblies for reliable performance.
PANEL & FRAME
Enamel painting is available in an off-white color, with options for powder coating, PU, and Duco finishes. Other colors are also available upon request.
CLADDING SHEET

PLAIN SHEET

ACRYLIC SHEET

TOP TRACK

BOTTOM TRACK
Single Side Pre-coated G.I Cladding Sheet Both Side Pre-coated G.I Cladding Sheet

Single side plain sheet (MS/GI) with custom-designed thickness and all-around beading, or both-side plain sheet (MS/GI) with the same custom-designed thickness and all-around beading, available

Transparent or multiwall translucent sheets available in thicknesses ranging from 2mm to 6mm.

Specially designed bottom guide tracks prevent door oscillation, tailored to the number of panels. Flush bottom rail ensures seamless operation at floor level.Custom-designed multiple bottom guide tracks, configured according to the number of panels, effectively preventing door oscillation. The bottom rail is seamlessly flushed with the floor level for smooth operation.
ACCESSORIES
OPERATIONAL ACCESSORIES:

Remote Control with receiver | Microwave Radar | Magnetic Loop Detector | Pull Cord Switch | Key Switch | Additional Push Button

SAFETY ACCESSORIES:

Safety Photocell | Light Grill sensor | Optical wired/wireless safety edge sensor

INDICATIVE ACCESSORIES:

Flashing Light | Flashing light with alarm

MECHANICAL ACCESSORIES:

Motor Cover | Fixed Bollards
OPERATING SWITCH
PUSH BUTTON FROM INSIDE
